| Bethlehem Express - Bretton Woods |
|
|
Image Courtesy Jeremy Clark |
Image Courtesy Jeremy Clark |
| Lift Stats: |
| Manufacturer: | Doppelmayr |
| Type: | High-Speed Quad |
| Installed: | 1989 |
| Drive: | At Bottom Station |
| Tensioning: | At Top Station |
| Motor: | 500 HP |
| Motor rating, continuous: | N/A kW |
| Motor rating, starting: | N/A kW |
| Haul rope diameter: | N/A mm |
| Rope guage: | N/A m |
| Vertical rise: | 1,010 ft / 307.85 m |
| Inclined length: | 4,900 ft / 1,493.52 m |
| Speed on line: |
1,000 fpm / 5.08 m/s |
| Speed in station: | 195 fpm / 1 m/s |
| Number of towers: | N/A |
| Number of carriers: | N/A pcs. |
| Capacity: | 2,500 P/h |
| Ride time: | ~5 minutes |
| Chair parking: |
Manual Rail at Bottom Station |
| Other notes: |
This lift was the first High-Speed Quad in New Hampshire |
